High-Pressure Combustor Test Facility

The high-pressure combustor test beds allow technology developments to be tested from their earliest stages through to advanced technological maturity. The test beds are constantly being adapted to meet new requirements. Our infrastructure covers various fuels, such as air, kerosene and special fuels, in order to optimally supply the systems depending on the research topic. The excellent hydrogen infrastructure at the DLR site in Cologne is a unique selling point in the European research infrastructure.

High-Pressure Combustor Test Facility 1

High-Pressure Combustor Test Facility 1 is a fully optically accessible combustion test bedfor the analysis of combustion chambers and burners for aircraft engines and stationary gas turbines.

High-Pressure Combustion Facility 2

Almost any test can be performed, from small can combustion chambers and multi-stage combustion systems to full ring tests on engine combustion chambers.

High-Pressure Combustor Test Facility 3

The size of the test stand allows the validation of combustor components with a thermal output of up to 9 megawatts.

High-Pressure Combustor Test Facility 5

True-to-scale tests are carried out with original combustion chambers in a component test without being restricted by the operating windows of the compressor and turbine.

High-Pressure-Cooling-Rig

More powerful, more efficient and lower-emission engines of the future require highly efficient cooling concepts with significantly reduced cooling air requirements.

Optical-High Pressure-Atomizer

The processing of liquid paraffin in newly developed burners is the focus of the Optical-High Pressure-Atomizer.
