Engine Measurement Systems

Optical measurement technology for engines at the Institute of Propulsion Technology of the DLR
The DLR Institute of Propulsion Technology has many years of experience in the design of laser-optic measurement equipment in the fields of probe design and manufacture, fibre-optic assembly and prototype construction.
Credit:

Alle Rechte vorbehalten

Test set-up at the Institute of Propulsion Technology
At the DLR Institute of Propulsion Technology, we use lasers to generate a so-called light section, also known as a transection. This makes individual planes in the focal area visible.
Credit:

Alle Rechte vorbehalten

Large-scale research facilities and test beds

The high-pressure combustion chamber test bed 1
The combustion test bench is fully optically accessible and is used to analyse combustion chambers and burners for aircraft engines and stationary gas turbines.
DownloadDownload
The CRAFT test bed offers a flexible test setup
In the unique CRAFT (Co/Contra-Rotating Acoustic Fan Test Rig) test environment, fan noise excitation can be analysed in detail. It is characterised by its modular test set-up.
DownloadDownload
Multistage test bench for twin-shaft compressors
The Institute of Propulsion Technology operates a large multi-shaft compressor test rig in Cologne, which provides ideal conditions for analysing high-efficiency multi-shaft high-pressure compressor configurations.
DownloadDownload
Calming chamber
The Multistage Twin Shaft Axial Compressor Test Stand is available for experimental testing of axial machines. It allows the investigation of a single or multi-stage compressor. In addition, counter-rotating compressors and fans or low-pressure/high-pressure compressor combinations can be operated at different speeds.
DownloadDownload
Transonic Cascade Wind Tunnel
The test bed operates in a closed loop, allowing the Reynolds number to be varied independently of the Mach number. Total pressure and total temperature can be adjusted independently.
DownloadDownload
Next Generation Turbine NGTurb - the world's largest turbine test bed
View of the brake train on the downstream side of the turbine of the NG-Turb test bench at the DLR site in Göttingen: Brake train with integrated torque measuring shaft, gearbox and emergency brake.
DownloadDownload
CFRP-manufactured fan blades
Innovative manufacturing technology for thermoplastic fibre composite rotor blades being tested on the multi-stage twin-shaft axial compressor test rig at the DLR Institute of Propulsion Technology in Cologne.
DownloadDownload
New combustion chambers for direct hydrogen combustion
In a joint measurement campaign, DLR and Rolls-Royce Germany have for the first time tested various hydrogen burners in a three-sector combustion chamber on the high-pressure combustion chamber test rig 1 at the DLR Institute of Propulsion Technology in Cologne under realistic operating conditions.
The Straight Cascade Tunnel
The large scale research facility is used for experimental investigations on flat turbine cascades with simplified flow and allows investigations over a very wide Mach number range. The facility is operated continuously in a closed loop with independent Mach and Reynolds number settings.
DownloadDownload
Multistage Two Shaft Compressor Test Facility
The compressor test rig at the DLR Institute of Propulsion Technology in Cologne enables a wide range of compressor analyses: Measurement of the complete compressor map, determination of the pumping limit, detailed flow field measurements and special applications such as active noise control on single-stage fans or counter-rotating propfans.
DownloadDownload
Radial compressor to validate new designs and numerical simulations
The Radial Compressor Test Bench is used for experimental testing of newly developed compressors. In addition to conventional measurement techniques, optical measurement methods and time-resolved sensors and measurement systems are used, which often have to be adapted to the extreme conditions.
DownloadDownload

Simulation and optimisation

3D view of a linear transonic compressor cascade
Visualisation of the flow field using resolved turbulent scales and the shock boundary layer system resulting from a large-eddy simulation (LES).
Credit:

alle Rechte vorbehalten

Simulation of low-pressure and high-pressure turbines interacting with the turbine centre frame.
