Sensor unit in the gas sensor array for measuring gas concentration, wind direction and wind speed
Sensor unit in the gas sensor array for measuring gas concentration, wind direction and wind speed
The gas sensor array is mounted on a mobile 3D volume scanner and can therefore move through space around three axes. A sensor unit is located on four levels. Each consists of an anemometer (ultrasonic wind sensor, above the circuit board), as well as sensors for temperature, humidity and gas concentration (below the circuit board).
