Production of an aluminium rotor for the 'CRAFT' compressor test bench (Counter Rotating Acoustic Fan Test rig) – a fan laboratory test bench for model experiments.
Manufacturing at Systemhaus Technik: plastics processing
Systemhaus Technik processes fibre composite materials for wind tunnel models and structural components. This process requires precise cutting of individual fibre layers, which are then bonded together with a resin matrix. Carbon fibre and glass fibre are primarily used.
For many test facilities, extensive assembly work and adjustments must be completed during test preparation. This often requires additional personnel and, in some cases, specialised knowledge and experience within a limited timeframe (for example, assembling wind tunnel models or work on the ground station of an air-to-ground communication device).
Despite thorough test preparation, the occurrence of faults during test operations unfortunately cannot be completely ruled out. To minimise interruptions, prompt on-site support is essential. Fault resolution in both hardware and software mainly involves troubleshooting and minor repairs that can be performed on site.
Test stands and test facilities are frequently adapted to meet current test requirements or upgraded to the latest technical standards. As a result, these facilities may undergo modifications, expansions or modernisation.
Systemhaus Technik portfolio
Assembly work on test facilities
Assembly and disassembly of models, test equipment and test facilities
Repairs to test facilities
Welding and fabrication of test equipment and custom constructions
Design and installation of supply lines
Flexible in-work implementation
Services are provided directly on-site by experienced personnel.
