Clamping Field

Experimental set-up on the Clamping Field

Components, that do not fit into our testing machines can be tested on our clamping field. With different hydraulic cylinders and our flexible measurement devices, both service life and proof of strength can be provided.

Facts Clamping Field

Horizontal

6 x 13 m   (b x l)

Vertical

6 x 4 m    (b x h)

Distance between profile rails

250 mm

Distance between strain achors

1 m
